ctrlX CORE X7
Accessories and spare parts
Bosch Rexroth AG
R911419122, Edition 01
15.2 Type code
18
18
Special variante
None .......................................................................................................................................... = NN
Robert Bosch 1 .......................................................................................................................... = B1
+
+
+
+
5
+
+
+
+
10
+
+
+
+
5
+
+
+
+
20
+
+
+
+
5
+
+
+
+
30
+
+
+
+
5
+
Type short description C O R E X - C - X 3 - 1 1 - A N N N - 2 1 . 0 1 - 0 1 R S - N N - N N
01
02
03
01
Product
ctrlX CORE .............. = COREX
02
Design
Kompakt................................... = C
Modular ....................................= M
03
Performance class
CPU version X2 ........................= X2
CPU version X7 ........................= X3
CPU version X7 ........................= X7
04
05
06
07
08
09
10
11
12
13
14
15
04
Device configuration
Device configuration 11..................................= 11
CPU basic device (2 GB RAM, 4 GB hard drive,
1 MBit retentive memory)
Device configuration 31..................................= 31
CPU basic device (16 GB RAM, 32 GB
hard drive, 2 MB retentive memory)
05
Standard interface
Configuration A ...................................................... = A
1 x HMI/Engineering, 1 x Fieldbus Master,
1 x configurable
Configuration B ......................................................= B
1 x HMI/Engineering, 1 x Fieldbus Master,
1 x configurable, 1 x IO-connection
06
Extension option 1
None .......................................................................... = N
MultiEthernet.............................................................. = 1
07
Extension option 2
None ............................................................................. = N
08
Extension option 3
None ................................................................................= N
09
Protection class
IP 20..........................................................................................= 2
10
Reserve
Reserve........................................................................................ = 1
11
Device version
01 ......................................................................................................... = 01
12
Runtime version
Version 01 ..................................................................................................... = 01
13
Runtime release
Aktuelles Release ................................................................................................. = RS
14
Extended certification
Kein................................................................................................................................. = N
15
Subject to export control (EU)
No export license required ...............................................................................................= N
Fig. 17: Type code
15.3 Accessories and spare parts
For ordering information on accessories and spare parts, refer to the chapter “Spare parts, accessories
and wear parts”.
Ordering information
