1070 072 449-102 (01.12) GB
Status Display 5-1
5 Status Display
The operational statuses of the module are shown on a 7 segment
display.
Furthermore, the operational statuses are divided into 4 groups:
• Static display
• Flashing display
• Alternating display with starting signal F
• Alternating display with starting signal H
7 segment display:
SEG_A
SEG_F SEG_B
SEG_G
SEG_E SEG_C
SEG_D
® decimal point
5.1 Static Display
Display Status
.
Normal operation (Operate Mode)
r.
Remote Test
<SEG_A>.
SYNC Mode
<SEG_D>.
FREEZE Mode
<SEG_A+SEG_D>.
SYNC/FREEZE Mode
0.
CLEAR Mode
1.
I/O diagnostic message
2.
LEAVE Master
3.
Offline
4.
-
5.
Parameterization error
6.
Configuration error
7.
-
8.
Hardware test active
9.
Peripheral bus Init
