Bosch RM2-DP12 User Manual

1070 072 449-102 (01.12) GB
I/O Modules 6-1
6 I/O Modules
6.1 Supply
The RM2-DP12 module provides the internal 7.5 V supply voltage for the
in- and output modules. The 7.5 V supply voltage can be loaded with a
maximum of 1.2 A.
Þ Please observe the limit value of the current!
Current input of the modules
Module Identifi-
cation
Number
Address
Assign-
ment
[Byte]
Current
Input
[mA]
E24V-, 16 inputs 075101 2 I 25 mA
E24V-, 32 inputs 075924 4 I 45 mA
A24V-/0.5A, 16 outputs 075098 2 O 60 mA
A24V-/0.5A, 32 outputs 078917 4 O 68 mA
A24V-/2A, 8 outputs 077418 1 O 40 mA
Relay, 8 outputs 077200 1 O 38 mA
E16/A8 081376 2 I / 2 O 45 mA
E16/A16 081661 2 I / 2 O 57 mA
Aana, analog output 077138 4 O 80 mA
A20 ana (4) 078914 8 O 70 mA
A10 ana (4) 078507 8 O 60 mA
A10 ana (8) 078295 16 O 60 mA
Eana, analog input 077141 32 I 80 mA
E20 ana 078911 32 I 80 mA
POS-SA1 077100 4 O
Fifo mode
10 mA
POS-SA2 077103 4 O
Fifo mode
10 mA
POS-LR1 078529 50 I / 48 O 1 mA
POS-LR2 078533 50 I / 48 O 1 mA
AG/S200 075916 30 mA
BM2-ASI 078284 24 I / 23 O 200 mA
Intelligent modules like e.g. R200, R200P, COM2-E are not supported.
