Bose 102 User Manual

14
1.4 Change both input sensitivity switches
to the 100 mV position.
1.5 The output should be 1 Volt rms,
(+20 dB
± 2 dB).
2. Music Channel Response Tests
2.1 Return both input sensitivity switches
to the 1 Volt position.
2.2 Apply a 1 Volt rms, 1 kHz signal to
both A and B inputs.
2.3 Reference a dB meter to the left or
right output, and perform the tests listed in
the 102 System Controller Frequency
Response table below.
102 System Controller Frequency Response
3. Channel Separation Test
3.1 Apply a 5 Volt rms, 1 kHz signal to the
channel A and B inputs.
3.2 Reference a dB meter to the channel
A output.
3.3 Remove the applied signal from
channel A.
3.4 The output should be > 50 dB down at
channel A.
3.5 Sweep the signal generator from
80 Hz to 13 kHz at 1 Volt rms.
102
®
SYSTEM CONTROLLER TEST PROCEDURES
3.6 The output should be > 50 dB down
at channel A.
3.7 Return the signal to channel A.
3.8 Repeat steps 3.2 thru 3.7 for
channel B.
4. Maximum Output Test
4.1 Apply an 8 Volt rms, 1 kHz signal to
the channel A and B inputs.
4.2 The output should be 8 Volts rms
for both channels. (0 dB ± 2 dB)
5. Distortion Test
5.1 Apply a 1 Volt rms, 1 kHz signal to
the channel A and B inputs.
5.2 The distortion should be < .1% at both
the channel A and B outputs.
5.3 Reduce the input signal to .5 Volt rms
and sweep the generator from 80 Hz to
12 kHz, measuring the distortion at
various frequencies.
5.3 The distortion should be < .1 % at
both the channel A and B outputs.
6. Mute Test
6.1 Set the Voice Input Switch to the MIC
position.
6.2 Apply a 1 Volt rms, 1 kHz signal to the
channel A and B inputs.
6.3 Reference a dB meter to the channel
A or B output.
6.4 Take another signal line from the
generator, or any other line level output
signal, and quickly add and remove the
signal to the positive (+) input terminal of
the voice channel.
Frequency
(Hz)
Bass
Switch
Response
(dB)
1,000 Normal 0 Reference
40 Normal 0 ± 4 dB
80 Normal +14 +/- 2 dB
100 Normal +12 +/- 2 dB
100 Decrease +7.5 +/- 2 dB
200 Normal +6 +/- 2 dB
4,000 Normal +7.5 +/- 2 dB
13,000 Normal +16 +/- 2 dB
20,000 Normal +6 +/- 4dB
