102 Flush-Mount Loudspeaker Installation Hardware
Description
*Part Number for
Product Code
000889 and
000887
*RoHS Part
Number for
Product Code
040134 and
040135
Qty
INSTALLATION HARDWARE KIT, QUAD SPEAKER 129036 294289-001 1
INSTALLATION HARDWARE KIT, SINGLE SPEAKER 125993 N/A 1
WB-16 WALL BRACKET KIT 125871 N/A 20 PACK
102
®
Flush-Mount Loudspeaker Parts Lists (per figures 11a and 11b)
17
*Product code 040134 (102F 75V 25 WATT) and 040135 (102F 100V 25 WATT) are a RoHS
compliant version of the 102F. Only RoHS compliant parts listed in the above chart can be
used in the 102F with product code 040134 (102F 100V 25 WATT) and 040135 (102F 70V
25 WATT). Both part numbers listed above can be used in the 102F product code 000887
and 000889.
Notes: 1. This component is not used in all versions of the 102 F Loudspeaker.
2. Hardware quantities vary according to variation.
Item
Number
Description *Part
Number for
Product
Code
000889 and
000887
*RoHS Part
Number for
Product Code
040134 and
040135
Qty Note
1 TRANSFORMER, AUDIO, 70V, 25W
TRANSFORMER, AUDIO, 100V, 25W
TRANSFORMER, POWER, 25V, 25W
TRANSFORMER, POWER, 100V, 8W
130147
130146
130237
125827
291499-001
291498-001
N/A
N/A
1 1
2 SWITCH, ROTARY, SINGLE POLE, 6
POSITION
130196
130196
1 1
3 CAP, 25uF, ELECTROLYTIC, BIPOLAR,
85C, 150V, 20%
125959 N/A 1 1
4 CAP, ELECTROLYTIC, BP, 85C, 50V,
10%, 5.0 uF
125780 N/A 1 1
5 RESISTOR, WIRE WOUND, 5W, 10%,
9.1 OHM
125605-9R1 N/A 1 1
6 INDUCTOR, 1.5mH 134705 N/A 1 1
7 DRIVER ASSY, 4.5", FIP, (8 OHM UNITS)
DRIVER ASSY, 4.5", (4 OHM &
TRANSFORMER UNITS)
124612-5
123561-5D
N/A
291024-001
1 1
8 GASKET, DRIVER, 4.5" 128407 128407 1
9 SCREW, MACHINE, 8-32X1.25, HEXW,
SLOT
171557-12 N/A 1 2
10 SCREW, HILO, 8-18x.75", HEXW, SLOT 171557-12 290977-12 7 2
11 WASHER, FLAT, .188", #8 143295-05 N/A 2
- GRILLE , WHITE (OPTIONAL) 125789 125789 1
- LOGO, BOSE®, CIRCULAR 128905 128905 1
- TERMINAL, WIRE WRAP 118008 118008 2
- ADAPTOR, GRILLE 127589 127589
- COVER, OCTAGONAL 126786 126786 1
