22
Reference Designator Description Part Number See
Note
DE01, DE02, DE03, DE51, DE52,
DE53, DE54, DG01, DG02, DG03,
DG04, DG32, DG35, DG61, DG62
Diode, ISS133 127376
D801, D802, D804, D805 Zener, RD16EB1 127378
DG34 LED, SLP5400, WHT 127382
DG63 LED, SEL 111OR, RD 127380
D803 LED, SEL 13103,
GRN
127381
D806 Diode, SLVB20 127377 1
QE01, QE02, QE03, QE51, QE52,
QG01, QG02, QG05
OP-AMP, 2043DD 127375
QG03 I.C., CA3080E 127374
QG04 OP-AMP, 4558 127373
QG31, QG33, QG34 Transistor, 2SC945 127385
QG32, QG61, QG62 Transistor, 2SA733 127383
QG36, QG37 FET, 2SK30 127379
Q802 Transistor, 2SD313 127386
Q803 Transistor, 2SB507 127384
102
®
System Controller Parts List
Semiconductors
Capacitors
Reference Designator Description Part Number See
Note
CE03, CE11, CE53, CE61, CG04 Ceramic, 330 pf 129314
CE04, CE14, CE54, CE64, CG08 Ceramic, 33 pf 129315
CE16, CE17, CE66, CE67, CJ01,
CJ02, CJ03, CG17
Ceramic, .01 uf 129316
C808, C809 Ceramic, .01 uf 129316 1
CE18, CE68 Ceramic, 1000 pf 130253
CG03, E68 Ceramic, 3300 pf 129317
CG05 Ceramic, 220 pf 129318
CG06 Ceramic, 22 pf 129319
CG18 Ceramic, 10,000 pf 129320
CE05, CE06, CE55, CE56 Film, .0056 uf, 5% 129321
CE07, CE57 Film, .047, uf, 5% 129322
Note:
1.
!
This part is critical for safety purposes. Failure to use a substitute replacement with the
same characteristics as the recommended replacement part might create shock, fire, and/or
other hazards.
!
!
