Description Part Number See
Note
T001 Transformer - 115 Volt
Transformer - 240 Volt
127392
127393
1
W001 Power Cord - 115 Volt
220 Volt
127395
127394
1
PCB Assembly 127364 2
Chassis - 110 Volt
220/240 Volt
127411
127412
Cover, Top 127410
Front Panel Assembly 127367
Knob 127421
JE01, JE51, JG01 Jack, 3-pin 127397
JE01, JE51 Jumper Cable, 3-pin 127401
JE02 Jack, 4-Pin 127398
JE02 Jumper Cable, 4-pin 127403
WE03 Jumper Cable, 3-pin 127402
SE01, SE51, SG01, SG32 Slide Switch, Gain, Sel. 127391
SG31 Push Switch, Bass 127390
Input Terminal, 4-Pole 127399
Output Teminal, 9-Pole 127400
Lug, Grounding 127429
Nut, Hexagon, Gnd. 127428
Screw - Cover, Front
Panel, Transformer 127425
Screw - Grounding 127427
Screw - PCB Hold Down 127422
Screw - Rear Terminals 127426
Screw - Accessory Kit 127423
Screw - Accessory Kit 127324
102
®
System Controller Parts list
Miscellaneous
102 System Controller Packing List
!
!
Note:
1.
!
This part is critical for safety purposes. Failure to use a substitute replacement with the
same characteristics as the recommended replacement part might create shock, fire, and/or
other hazards.
2. This part is not normally available from Customer Service. Approval from the Field Service
Manager is required before ordering.
Description Part Number
Carton 127415
Filler 127416
Owner's Guide 125966
Registration Card 125967
