Bose SoundTouch 520 User Manual

English - 23
Programming the universal remote control
You can use the remote to control your TV, cable/satellite box, DVD or
Blu-ray Disc
™
player, game system, DVR or other auxiliary source.
Consumer Electronics Control
The system supports Consumer Electronics Control (CEC). CEC allows you to
control multiple HDMI
™
-connected sources without programming the remote. You
can turn on/off CEC using the System menu (see page 31).
Your source may support CEC, but refer to it with a different name. Refer to your
source owner’s guide for more information.
CEC controls sources connected to
the console’s HDMI connectors.
Tip: You may need to use your source or TV’s system menu to enable CEC. Refer
to your source owner’s guide for more information.
Test your HDMI™ connected sources for CEC
If your sources successfully respond to their corresponding source buttons, you do
not have to program your remote.
Note: Your HDMI connected source may not support CEC. Refer to your source
owner’s guide for more information.
1. Power on the Bose
®
system, your TV, and the source you are testing.
2. Press a variety of buttons that correspond with your source’s functions.
3. Press the
button. The source powers off.
If your source does not perform one of the functions, program the remote
control (see page 23).
Using the System

Bose SoundTouch 520 Specifications

General

HDMI in	4
SCART ports quantity	0
Number of HDMI outputs	1
Digital audio optical out	-
AC input voltage	100-240 V
Built-in HDD	No
Wireless connection	Yes
Bluetooth range	9 m
Cables included	AC, HDMI, USB
Optical disc player type	Not included
RMS rated power	- W
Audio output channels	5.1 channels
Product color	Black

Weight and Dimensions

Main unit weight	1490 g
Subwoofer weight	3400 g
Center speaker weight	1000 g
Main unit dimensions (WxDxH)	313 x 208 x 64 mm
Subwoofer dimensions (WxDxH)	197 x 375 x 286 mm
Center speaker dimensions (WxDxH)	84 x 40 x 185 mm
