Bose SoundTouch 520 User Manual

English - 37
Factory reset the system
To troubleshoot problems, reset the System menu and the ADAPTiQ
®
audio
calibration to the factory settings.
1. Press
on the remote control.
2. Press
until 16 FACTORY RESET appears on the display.
3. Press 5.
The system resets.
4. Run the ADAPTiQ audio calibration
(see page 20).
Reset a source button on the remote control
If you are experiencing problems with a source button on the remote control, reset
the source button to the factory settings.
After performing this procedure, your source button is in CEC mode.
1. On the remote control, press and hold the appropriate source button until all
six source buttons glow, then release.
Only the appropriate source button glows.
2. On the number keypad, enter 0140.
Service connectors on the Acoustimass
®
module
The Service and Data connectors are for service use only. Do not insert any cables
into these connectors.
Care and Maintenance

Bose SoundTouch 520 Specifications

General

HDMI in	4
SCART ports quantity	0
Number of HDMI outputs	1
Digital audio optical out	-
AC input voltage	100-240 V
Built-in HDD	No
Wireless connection	Yes
Bluetooth range	9 m
Cables included	AC, HDMI, USB
Optical disc player type	Not included
RMS rated power	- W
Audio output channels	5.1 channels
Product color	Black

Weight and Dimensions

Main unit weight	1490 g
Subwoofer weight	3400 g
Center speaker weight	1000 g
Main unit dimensions (WxDxH)	313 x 208 x 64 mm
Subwoofer dimensions (WxDxH)	197 x 375 x 286 mm
Center speaker dimensions (WxDxH)	84 x 40 x 185 mm
