Attaching Patches or Emblems to Shirt Sleeves
Sewing S-39
UTILITY STITCHES
S
Use these stitch patterns to attach patches or emblems to
pant legs, shirt sleeves, etc.
• Using the table below, refer to “Using the utility
stitch tables in the “Sewing” section” in the “Basic
operations” section.
Insert the tubular piece of fabric onto the free-arm, and then
sew in the order shown in the illustration.
a
Remove the flat bed attachment.
b
Attach monogramming foot “N”.
c
Select stitch .
d
Lower the needle into the fabric at the beginning of the
stitching, and then start sewing.
Lower the needle at the upper-right corner.
→ The fabric is fed toward the back of the machine, as
usual.
e
After you have sewn to the corner, stop the machine,
and then select stitch .
f
Start sewing.
→ The fabric is fed to the right.
g
After you have sewn to the corner, stop the machine,
and then select stitch .
h
Start sewing.
→ The fabric is fed forward.
i
After you have sewn to the corner, stop the machine,
and then select stitch .
j
Start sewing.
→ The fabric is fed to the left.
Attaching Patches or Emblems to Shirt Sleeves
Stitch name Stitch
Model 4
Presser foot
Model 3, 2
Model 1
Stitch number
Reverse
(Straight stitch)
5-01 92 —
N
Sideways to left
(Straight stitch)
5-02 93 —
Sideways to right
(Straight stitch)
5-03 94 —
Forward
(Straight stitch)
5-04 95 —
Sideways to left
(Zigzag stitch)
5-05 96 —
Sideways to right
(Zigzag stitch)
5-06 97 —
Forward
(Zigzag stitch)
5-07 98 —
Reverse
(Zigzag stitch)
5-08 99 —
13
4
2
