3 - 13
Main parts
Application of Di
sassembly
Application
2-10
Removal of Decoration cover
1.
Remove the 3 screws
1
, and then remove the decoration cover
1
.
1
1
2-11
Removal of Front cover thread guard
1.
Remove the front cover thread guard
1
.
1
2-12
Removal of Thread guide wire
1.
Remove the thread guide wire
1
.
1
59
61
