Brother DCP 8085DN Service Manual

4-2
Confidential
1.1 Periodical Replacement Parts
Periodical replacement parts are the parts to be replaced periodically to maintain product
quality. These parts would affect the product quality greatly if they lost their function even if
they do not appear to be damaged or there is no change in their appearance.
The periodical replacement parts listed below should be replaced at the service center
referring to the service life.
To reset the count of each periodical replacement parts, refer to "5.1 Resetting the Periodical
Replacement Parts Life" in Chapter7.
*1
At 5% print coverage (A4 or Letter size). The actual number of printed pages will vary
depending on the print jobs and paper you use. The number is calculated when simplex
printed the normal business document (ISO/IEC19752) on the A4 size.
*2
Paper feeding kit MP means the MP roller holder ASSY and the separation pad ASSY MP.
*3
Paper feeding kit for Tray 1, Tray 2 and Tray 3 means the roller holder ASSY, the separation
pad ASSY and the separation pad spring. Tray 1, Tray 2 and Tray 3 are the same kit.
Parts Name
LCD Message
(HL-5380DN)
Qty
Approximate Life
*1
(number of prints)
Replacement
Procedure
Fuser Unit REPLACE FUSER 1 100,000 pages See subscription
1.2.1, Chapter 4
Laser Unit REPLACE LASER 1 100,000 pages
PF kit for Tray 1
*3
REPLACE PF KIT1 1 100,000 pages See subscription
1.2.2, Chapter 4
PF kit for Tray 2
*3
REPLACE PF KIT2 1 100,000 pages
MP PF tray
*2
REPLACE PF KIT MP 1
Except for China/
India: 50,000 pages
See subscription
1.2.3, Chapter 4
China:
25,000 pages
India:
12,000 pages
Note :
• Always turn off the power switch of the printer and unplug the power cord from the
power outlet before replacing the periodical replacement parts.
• If the Fuser Unit is replaced after errors related to the Fuser Unit occur, it is necessary to
leave the printer power ON for ten minutes after part replacement. This will make the
printer to be released from errors.
• After disconnecting flat cables, check that each cable is not damaged at its end or short-
circuited.
• When connecting flat cables, do not insert them at an angle. After insertion, check that
the cables are not at an angle.

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
