Brother DCP 8085DN Service Manual

7-19
Confidential
4.11 PC Print Function (Function code 43)
<Function>
This function allows the machine change that the setting of each PC printing function
indicated to the following function settings.
<Operating Procedure>
(1) Press the [4] and [3] keys in this order in the initial stage of the maintenance mode.
The “Manual Feed” will appear on the LCD.
(2) Press the [ ] or [ ] buttons to select the function you want to set and press the [OK]
button.
(3) When select the unchanging (On/Off) parameter, press the [ ] or [ ] button, or change
the parameter using the numeric keys. And press the [OK] button.
(4) If press the [Stop] button, the machine will return to the initial stage of the maintenance
mode.
■ Function setting
LCD indication Description Set value
Initial
value
Manual Feed Switching of the Manual Feed On/Off Off
Resolution Resolution to print 300/600/1200dpi 600
Toner Save Switching of the Toner Save On/Off Off
Density Switching of the Density level -6 to 6 0
Job Cancel
TimeOut
Setting of the time until the host
time-out at the Job Cancel
2 to 225 (seconds)
4
Sleep Time Setting of the time until enter the
Sleep Mode
0 to 99 (minutes)
5
Pege
Protection
Switching of the protection of the
page memory
Off/Letter/A4/Legal/Auto
Off
Emulation Switching of the emulation Auto/HP/PS Auto
Auto I/F Time Switching of the I/F open time 1 to 99 (seconds) 5
Media Type Switching of the recording paper
type
Thin/Plain/Thick/Thicker/
Trancparency/Recycled/
Bond/Envlopes/EnvThin/
EnvThick
Plain
Paper(Size) Switching of the area of develop the
Letter/Legal/A4/
Executive/B5/JISB5/A5/
B6/A6/Monarch/C5/
COM10/DL/DLL/
A4Long/PostCard/Folio
Letter
Copies Switching of the print copies 1 to 99 (pages) 1
Orientation Switching of the print direction PortLait/Landscape Portlait
P-Pos X-Offset Switching of the offset print position
of the landscape orientation
-500 to 500 (1/300dpi)
0
P-Pos Y-Offset Switching of the offset print position
of the portrait orientation
-500 to 500 (1/300dpi)
0
AutoFF Switching of the auto form feed On/Off Off

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
