Brother DCP 8085DN Service Manual

3-5
Confidential
2. DISTINGUISH ERROR CAUSE
2.1 ERROR INDICATION
To help the user or the service personnel promptly locate the cause of a problem (if any), the
facsimile equipment incorporates the self-diagnostic functions which display error messages
for equipment errors and communications errors.
For the communications errors, the equipment also prints out the transmission verification
report and the communications list.
2.1.1 Error messages appearing on the LCD
Error Message Type of Error Action
Refer
to
Access Error The device is removed
from the USB direct
interface while the data is
processing.
Press Stop/Exit. Reinsert the device
and try to print with Direct Print.
-
Cartridge Error The toner cartridge is not
installed properly.
Pull out the drum unit, take out the
toner cartridge that is indicated on
the LCD, and put it back into the
drum unit again.
3-34
Replace Parts
Drum
The drum unit is the end of
its life.
Replace the drum unit.
3-14
The drum unit counter was
not reset when a new drum
was installed.
1) Open the front cover, and then
press Clear/Back.
2) Press 1 to reset.
Replace Parts
Fuser Unit
It is time to replace the
fuser unit.
Replace the fuser unit.
3-15
Replace Parts
Laser Unit
It is time to replace the
laser unit.
Replace the laser unit.
3-15
Replace Parts
PF Kit MP
It is time to replace the
paper feeding kit for the
MP tray.
Replace the PF Kit MP.
3-14
Replace Parts
PF Kit 1
It is time to replace the
paper feeding kit for Tray
1.
Replace the PF Kit 1.
3-15
Replace Parts
PF Kit 2
It is time to replace the
paper feeding kit for Tray
2.
Replace the PF Kit 2.
3-15
Comm.Error Poor telephone line quality
caused a communication
error.
Send the fax again or connect the
machine to another telephone line. 3-62
Connection Fail You tried to poll a fax
machine that is not in
Polled Waiting mode.
Send the fax again.
-

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
