Brother DCP 8085DN Service Manual

7-10
Confidential
4.6 Firmware Switch Setting and Printout
4.6.1 Firmware switch setting (Function code 10)
<Function>
The machine incorporates the following firmware switch functions which may be activated
with the procedures using the control panel keys and buttons.
The firmware switches have been set at the factory in conformity to the communications
standards and codes of each country. Do not disturb them unless necessary. Some
firmware switches may not be applicable in some versions. The firmware switch data list
indicates "Not used." for those inapplicable switches.
■ Firmware Switches (WSW01 through WSW74)
WSW No. Function Refer to:
WSW01 Dial pulse setting App. 1-4
WSW02 Tone signal setting App. 1-6
WSW03 PABX mode setting App. 1-7
WSW04 TRANSFER facility setting App. 1-9
WSW05 1st dial tone and busy tone detection App. 1-10
WSW06 Redial/Pause button setting and 2nd dial tone detection App. 1-11
WSW07 Dial tone setting 1 App. 1-13
WSW08 Dial tone setting 2 App. 1-14
WSW09 Protocol definition 1 App. 1-15
WSW10 Protocol definition 2 App. 1-16
WSW11 Busy tone setting App. 1-17
WSW12 Signal detection condition setting App. 1-18
WSW13 Modem setting App. 1-19
WSW14 AUTO ANS facility setting App. 1-20
WSW15 REDIAL facility setting App. 1-21
WSW16 Function setting 1 App. 1-22
WSW17 Function setting 2 App. 1-23
WSW18 Function setting 3 App. 1-24
WSW19 Transmission speed setting App. 1-25
WSW20 Overseas communications mode setting App. 1-26
WSW21 TAD setting 1 App. 1-27
WSW22 ECM and call waiting caller ID App. 1-28
WSW23 Communications setting App. 1-29
WSW24 TAD setting 2 App. 1-30
WSW25 TAD setting 3 App. 1-31
WSW26 Function setting 4 App. 1-32
WSW27 Function setting 5 App. 1-34
WSW28 Function setting 6 App. 1-35
WSW29 Function setting 7 App. 1-36
WSW30 Function setting 8 App. 1-37
WSW31 Function setting 9 App. 1-38
WSW32 Function setting 10 App. 1-39

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
