Brother HL-2030 User Manual

Control panel
3 - 5
3
Service call indications
If there is an error that cannot be cleared by the user, the printer will show that a service call is needed by
lighting up all the LEDs as shown below.
If you see the service call indication above, turn off the power switch, wait a few seconds, and then turn it
back on and try to print again.
If you cannot clear the error and see the same service call indication after turning the printer back on, call
your dealer or a Brother authorized service representative.
When you press the Go button, the LEDs will light up as shown in Table 1. See Table 1: LED indications while
pressing Go button on page 3-6 to identify the error.
For example, the LED indication below shows a fuser unit failure.

Brother HL-2030 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Internal memory	8 MB
Processor model	SPARClite
Built-in processor	Yes
Powersave acoustic emission	30 dB
Sound pressure level (printing)	51 dB
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 161 g/m2 (16 - 43 lb)
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Compatible operating systems	Windows 98 / Me / 2000 / XP Mac OS 9.1 - 9.2 Mac OSX 10.2.4+
Total input capacity	250 sheets
Total output capacity	100 sheets
Power consumption (standby)	70 W
Power consumption (printing)	450 W

Weight and Dimensions

Dimensions (WxDxH)	371 x 361 x 165.5 mm
