4. PREPARATION BEFORE SEWING
26KE-430F, BE-438F
4. PREPARATION BEFORE SEWING
4-1. Installing the needle
CAUTION
Turn off the power switch before installing the needle, otherwise the machine may operate if the foot switch is depressed
by mistake, which could result in injury.
1. Loosen the set screw (1).
2. Insert the needle (2) in a straight line as far as it will go,
making sure that the long groove on the needle is at the
front, and then securely tighten the screw (1).
4-2. Threading the upper thread
Thread the upper thread correctly as shown in the illustration below.
* When using threading mode for threading, the tension discs (1) will open so that the thread can be threaded more easily. (Refer
to following page.)
2300B
2301B
pprox. 40mm
[Two holes]
Spun rayon yarn
Synthetic thread
[One hole]
[When using the needle cooler (option)]
To Next Page
