Brother QL-1050 User Manual

9
Connect the power cord to the
QL label printer and then plug the
power cord into a 120V AC
electrical outlet.
• Check that the electrical outlet is 120V
AC before plugging the power cord.
• Unplug the power cord from the
electrical outlet after you have finished
using the QL-1060N.
• Do not pull the power cord when
unplugging it from the electrical outlet.
The wire in the power cord may
become damaged.
• Do not connect the QL label printer to
the computer until directed to do so
when installing the printer driver. For
how to install the printer driver and
software, refer to
Î "Software
installation Guide".
3
Thread the end of the DK Roll into
the slot until it can be seen from the
other side.
When unable to thread the end of the
DK Roll into the slot, thread it as far as
possible, and then close the cover.
Press the ON/OFF button to turn the
QL label printer on, and then press the
FEED button to set the roll.
4
Close the DK Roll compartment cover until it
clicks on both sides.
4 Connecting the Power Supply

Brother QL-1050 Specifications

General

Print technology	Direct thermal
USB port	Yes
Standard interfaces	USB 2.0, Serial
USB 2.0 ports quantity	1
Tape type	DK
Internal memory	2 MB
Number of styles	6
Built-in barcodes	EAN128, EAN13, EAN8, PDF417, QR Code, UPC-A, UPC-E
Tape size	62 mm
Dimensions (WxDxH)	170 x 220 x 147.5 mm
Bundled software	P-touch editor
Maximum label width	102 mm
Maximum label length	3 m
Minimum RAM	128 MB
Minimum storage drive space	70 MB
Compatible operating systems	Windows 2000/XP/Vista Mac OS 10.1-10.4.7

Weight and Dimensions

Weight	1700 g
