FRONT PANEL
USB INPUTS: Two USB
A
receptacles are
located on the front panel and four more are
located on the rear panel. These are USB-2
inputs but are USB-1 compatible. See also item
8 on the next page
INFRA-RED SENSOR for IR remote con-
trols such as Bryston’s BR2. The BR2 can re-
motely control the basic drive functions (PLAY,
PAUSE, STOP, PREVIOUS,NEXT)
DOT MATRIX DISPLAY: Approximately two
rows of 23 characters and/or graphics
FILE/FOLDER NAVIGATION KEYS: (UP
, DOWN , LEFT , RIGHT ) Use the
UP and DOWN keys to step through list
of connected USB data devices (flash drives
and disk drives). Then use the Right key to
select a device. If the files are located within
nested folders then navigate through the fold-
ers with the and keys pressing the key to
select a folder and load a list of playable files
within the selected folder. If the PLAY button
is pressed at this point, the BDP-2 will com-
mence playing all song files in that folder.
Folders are identified by a icon and indi-
vidual music files are indicated by the icon.
Subsequent playable files will automatically
be played from this point in the file list until
the last playable file in the selected folder is
played. See also Operational Notes
FUNCTION KEYS: PLAY, PAUSE, STOP, PRE-
VIOUS & NEXT; these keys function in essen-
tially the same manner here as they would on
a CD player like the BCD-1
POWER SWITCH & LED INDICATOR:
When the LED above the power switch is lit
red the unit is on standby, when it is lit green,
the unit is fully powered up. If your unit is
equipped with a blue/red LED, then blue rep-
resents the power ON state. See also Remote Trigger
section
REAR PANEL
RS232 ports: For connecting hard wired
control systems like AMX, Crestron, etc.
ETHERNET Ports: CAT-5 (or CAT-5e or CAT-
6) connections using an 8P8C (RJ45) connector
to interface with a home computer network to
BDP-2 REAR PANEL:
BDP-2 FRONT PANEL:
