facilitate remote control of the BDP-2 via per-
sonal computers and other networked devices
like iPhone/iPad Touch/iPad, SmartPhones run-
ning Android, etc.
USB INPUTS: The BDP-2 is supplied with
six USB-2 ports; two on the front panel and
four on the rear panel. When connecting port
powered USB hard disc drivesnote that each
USB port is limited to 50mA. All USB ports are
USB-2 but are USB-1 compatible. All are USB
ports are type A receptacles
eSATA Hard Disc Drive Connector:
Drive must be independently powered.
SPDIF Output (75 Ohm BNC connector): A
Sony/Philips Digital Interface output port for
connection to an outboard digital-to-analog
converter like Bryston’s BDA-1
AES/EBU Output (3 pin XLR male connector)
An AES/EBU output port for connection to
an outboard digital-to-analog converter like
Bryston’s BDA-1
REMOTE POWER ON/OFF TRIGGER CON-
TROL:
The BDP-2 is equipped with two 3.5mm two
conductor phone jacks for implementing a
remote power On/Off function. Supplying a
DC control voltage between 3 and 12 volts (at
greater than or equal to approximately 1mA)
to the Trigger IN port will allow you to re-
motely power your BDP-2 on or off. Whatever
control voltage is applied to the IN port will
be routed to the OUT connector, via an iso-
lated relay, after the BDP-2 has fully powered
up. This OUT port can then be used to control
other devices that are similarly equipped. The
the Remote Trigger input takes precedence
over the front panel push-button switch and
as long as a valid control voltage is present at
the BDP-2’s Trigger IN port the unit cannot be
powered Off. See illustration on next page.
DATA PLATE: This label provides the units
exact model number, serial number, electrical
rating and date of manufacture. Do not re-
move.
IEC Power Inlet: The IEC-320 C14 power
inlet accepts IEC-320 C13 equipped power
cords. Use only appropriate power cords that
have been approved for your region.
BDP-2 DIGITAL PLAYER
