4.5 A
V Unit and Fan (FN907) Remo
val
Remove the 5 screws holding the A
V unit
and the 3 screws holding the fan and
remove the A
V unit and fan.
4.6 Lamp Ballast Unit Remo
val
Remove the 6 screws and then remove
the lamp ballast unit.
P
ar
t 2: Repair Inf
or
mation
2-8
Fig.
2-8
Fig.
2-9
A
V unit
FN907
Lamp ballast
32
34
