Part 3: Adjustment
1.4 IC Adjustment Data
PC YCbCr
NTSC PAL
1 001 R-VIDEOCNT M62392FP A03
2 002 G-VIDEOCNT M62392FP A02
3 003 B-VIDEOCNT M62392FP A01
4 004 R-SubBright L3E7050K0A 102h
5 005 G-SubBright L3E7050K0A 502h
6 006 B-SubBright L3E7050K0A 902h
7 007 R-SubGain L3E7050K0A 101h 500 550 550
8 008 G-SubGain L3E7050K0A 501h 500 550 550
9 009 B-SubGain L3E7050K0A 901h 500 550 550
10 00A REF-R M62392FP A09
11 00B REF-G M62392FP A08
12 00C REF-B M62392FP A07
13 00D
14 00E
15 00F
16 010 G-GammaShift (L3E7050K0A) 140
17 011 R-GammaShift (L3E7050K0A) 140
18 012 B-GammaShift (L3E7050K0A) 140
19 013 BVCOM M62393FP A08
20 014 GVCOM M62393FP A07
21 015 RVCOM M62393FP A06
22 016 NRS-B M62393FP A01
23 017 NRS-A M62393FP A02
24 018 SubBright Matrix 63 66 66
25 019 SubColor Matrix 0 0 0
26 01A SubTint Matrix 32 32 32
27 01B SubSharpness MAtrix 8 0 0
→
See
28 01C SubBright (Video) Micronas FP:0x52 16 14
29 01D SubCont (Video) Micronas FP:0x53 60 61
30 01E SubColor (Video) Micronas FP:0x30 2070 2070
31 01F SubTin (Video) Micronas FP:0xDC 0 0
32 020 YC Delay Micronas FP:0x23 62 62
33 021 SubSharpness PW164 0 0
34 022 Vertical line shading correction [R1] L3E7050K0A C47
35 023 Vertical line shading correction [R2] L3E7050K0A C48
36 024 Vertical line shading correction [R3] L3E7050K0A C49
37 025 Vertical line shading correction [G1] L3E7050K0A C4C
38 026 Vertical line shading correction [G2] L3E7050K0A C4D
39 027 Vertical line shading correction [G3] L3E7050K0A C4E
40 028 Vertical line shading correction [B1] L3E7050K0A C51
41 029 Vertical line shading correction [B2] L3E7050K0A C52
42 02A Vertical line shading correction [B3] L3E7050K0A
Temp Node Real
Temp Node Real
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
Temp Node
C53
43 02B
44 02C Color shading ON/OFF DAC62392
45 02D LampLifeTime Display only
46 02E BauRate 0;9600/ 1;19200/ 2;38400
47 02F ShootOutMode 0;Normal/ 1;Shoot out1/ 2;Shoot out2
range
48 030 FAN CONTROL (Normal) 0-2 0:Max 1:min 2:Normal
49 031 FAN CONTROL (Cooling) 0-2 0:Max 1:min 2:Normal
50 032 FAN CONTROL (Service) 0-1 0:Max 1:min 2:Normal
51 033 Sensor Start 10-90
52 034 Sensor Stop 10-90
53 035 Shut Down1 10-90
54 036 Shut Down2 10-90
55 037 Shut Down3 10-90
56 038 Shut Down2-1 0-50
57 039 Shut Down3-1 0-50
58 03A OverTempCount 1-9
59 03B SensorErrorCount 1-9
60 03C TempDeltaErrorCount 1-9
61 03D TempDeltaEnableRange 48-160 48:3ºC-160:10ºC 0.0625ºC/step
62 03E Sampling 3-9 3:1.5sec-9:4.5sec 0.5sec/step
63 03F Cooling Time 0-6 n
×
30sec
64 040 InitialLevel 80-255
65 041 InitialTime 1-30
66 042 IgnoreTempFail 1-5
67 043 update 0-1
68 044
69 045
70 046
71 047
72 048
DetailBitAddressDeviceNAME
80
130
130
44
48
4
5
5
80
70
1
254
251
130
N/A
N/A
N/A
251
255
160
100
A value of 48 to 65 (except 51 and 52) is actually
reflected. Data in this range must be changed
from 67 to 1 after adjustment.
0
Contrast linearity adjustment
White balance adjustment
Signal center DC voltage adjustment
Contrast adjustment
Signal level adjustment
100
100
100
0
0
Video
Default
150
150
150
HEXDEC
2
10
1
55
30
2
N/A
170
1
3
3
52
N/A
Flicker adjustment
NRS adjustment
255
254
251
160
160
N/A
Vertical line shading correction
5
255
254
FAN CONTROL
Horizontal resolution
Lower 720 8
720-832 8
832-1024 12
1024 or higher 15
Service 27
