48 Routine Maintenance
Aligning the Print Head
If ruled lines are printed misaligned or print results are otherwise unsatisfactory, adjust the print head
position.
Automatic Print Head Alignment
1 Make sure that the machine is turned on, open the Front Feeder, and extend the
Output Paper Support.
2 Load a sheet of A4 or Letter-sized plain paper in the Auto Sheet Feeder or Front
Feeder.
Set the Paper Thickness Lever to the left.
3 Press the Paper Feed Switch to select the paper source where you have loaded
paper.
4 Print the Print Head Alignment Sheet.
(1) Press the Menu button.
(2) Use the [ or ] button to select Maintenance/settings, then press the OK button.
The Maintenance/settings screen is displayed.
(3) Use the [ or ] button to select Maintenance, then press the OK button.
The Maintenance screen is displayed.
(4) Use the { or }
button to select Auto head
align and then press the OK button.
The confirmation screen is displayed.
(5) Use the { or }
button to select Yes and then
press the OK button.
The Print Head Alignment Sheet is printed.
Note
If you select Head alignment print, the machine
exits the process after printing the current head
position adjustment values.
(4)
(5)
To Next Page
