2-5
Setting Up
1. Set Up the Camera
-
Note
● The camera may not operate correctly if a wide converter other than the WL-37
is used.
● Be sure to install the VB-C50Fi firmly because the weight of the camera increases
when the optional Wide Converter WL-37 is attached.
● If you use the optional Wide Converter WL-37, set the zoom lens to the wide-angle
end. If you set the zoom lens to the telephoto end, the image resolution will be
affected and the auto focus might have problems.
Using the Wide Converter
The optional Wide Converter WL-37 can be used to provide wide-angle shots (approx. 0.74× the
normal focal distance).
Mount the wide converter correctly so that it is level and fitted securely onto the camera. When
mounted correctly, the wide converter should turn roughly 3 times before stopping.
○○○○○○
Setup is now complete.
Wide Converter
To Next Page
