Canton Smart Amp 5.1 Short Manual

36
English
DISPLAY INDICATIONS
The Amp 5.1 has an On-Screen Display (menu visible on the TV), a LED status
indicator (green or red) and a LED display (in the front of the Amp 5.1).
On-Screen Display
All settings and the configuration of the Amp 5.1 can be conveniently performed
via the On-Screen Display on your TV screen. To do this, the Amp 5.1 must be
connected to your TV via an HDMI
®
cable. The menu is simple and structured and
all changes you make on the Amp 5.1 are displayed on your TV. By pressing the
menu button (M) on the Smart-remote, you can access the main menu.
Practical tip:
• To change the language of the On-Screen Display from German to English,
please go to the main menu by pressing the button „M“. Under „System-
einstellung“ [SYS] select the menu item „Displayeinstellungen“ [UIS] and
change the language under the menu item „Sprache“ [LAN].
LED status indicator
When you switch on the Amp 5.1, the Status LED lights up green. In standby
mode, the Status LED lights up red.
LED display
The LED display is located in the front of the Amp 5.1 and lights up for five
seconds when a command is sent. It indicates the selected function as
abbreviation or scroll text. The most important display indications and their
meanings are listed here:

Canton Smart Amp 5.1 Specifications

General

Video in	3x HDMI
Video out	1x HDMI
Ethernet LAN (RJ-45) ports	1
Speakers connectivity type	-
Product color	Black
Volume control	Touch
Cables included	AC
Treble adjustment	Yes
Connectivity technology	Wired & Wireless
Audio decoders	DTS-HD, Dolby Atmos
Audio output channels	- channels
Peak power per channel	600 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %

Weight and Dimensions

Depth	154 mm
Width	245 mm
Height	120 mm
Weight	5240 g
