Canton Smart Amp 5.1 Short Manual

40
English
CONNECTION TO OTHER DEVICES
HDMI
®
(recommended)
To connect other digital devices such as a satellite receiver, Blu-ray player,
game console etc., it is recommended to connect them via one of the 3
HDMI
®
inputs of the Amp 5.1.
1
Connect one of the 3 HDMI IN (HD1/HD2/HD3) on the back of the Amp 5.1
and the HDMI OUT output of your digital source using a HDMI
®
cable.
2
Now, select the used input [BDP] for HD1, [SAT] for HD2 or [PS] for HD3
with the up or down arrow key ( / ) on the Smart-remote.
Note:
• Make sure that you do not connect the other playback devices to the TV,
but directly to the Amp 5.1. This is the only way to ensure that the best
possible multichannel audio format / audiosignal is reproduced.
Optical digital input (alternative)
1
Connect the input OPTICAL at the Amp 5.1 to the OPTICAL OUT connector
of your TV using an optical cable (TOSLINK).
2
On the Smart-remote, use the up and down arrows ( / ) to select the input
[CD].
Notes:
• If the optical digital input is already in use, please use one of the other
unused inputs (COAX and/or LINE).
• Make sure you have removed the protective caps from both ends of the
optical cable, if present.

Canton Smart Amp 5.1 Specifications

General

Video in	3x HDMI
Video out	1x HDMI
Ethernet LAN (RJ-45) ports	1
Speakers connectivity type	-
Product color	Black
Volume control	Touch
Cables included	AC
Treble adjustment	Yes
Connectivity technology	Wired & Wireless
Audio decoders	DTS-HD, Dolby Atmos
Audio output channels	- channels
Peak power per channel	600 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %

Weight and Dimensions

Depth	154 mm
Width	245 mm
Height	120 mm
Weight	5240 g
