Canton Smart Amp 5.1 Short Manual

46
English
USING AirPlay 2 TECHNOLOGY
With Apple AirPlay technology, you can play audio content over the wireless
network (WLAN) using your Smart Amp 5.1.
Additionally, AirPlay 2 technology offers you the possibility to play your
content on several amplifiers and/or loudspeakers synchronously.
Connecting the Smart Amp 5.1 to the WLAN (WiFi network) via iPhone, iPad
or iPod touch
To connect your Smart Amp 5.1 to your WLAN (WiFi network) via iPhone, iPad
or iPod touch, please proceed as follows:
1
Connect your Amp 5.1 to the power outlet and wait until the display (once)
shows [NET] followed by [SET].
2
On your iPhone, iPad or iPod touch, select „Settings“ and then „Wi-Fi“
(WLAN).
3
Under the menu item „SET UP NEW AIRPLAY SPEAKER“ select the Smart
Amp 5.1 as the device to be installed.
4
The „AirPlay Config...“ window opens.
a. Under „Network“ select the network to which you want to
connect the Smart Amp 5.1.
b. Under “Speaker name” enter the name (synonym) you want to
assign to the Amp 5.1.
c. Optionally, you can assign a password under
„SPEAKER PASSWORD“.
d. Select the function „Next“ and wait (approx. 30 seconds) until the
Amp 5.1 shows [WIF] / [CON] in the display.
5
Finalize the registration process in the „Configuration finished“ window
that opens by pressing the „Done“ button. The Smart Amp 5.1 is now
connected to your WLAN (WiFi network) and ready for use.

Canton Smart Amp 5.1 Specifications

General

Video in	3x HDMI
Video out	1x HDMI
Ethernet LAN (RJ-45) ports	1
Speakers connectivity type	-
Product color	Black
Volume control	Touch
Cables included	AC
Treble adjustment	Yes
Connectivity technology	Wired & Wireless
Audio decoders	DTS-HD, Dolby Atmos
Audio output channels	- channels
Peak power per channel	600 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %

Weight and Dimensions

Depth	154 mm
Width	245 mm
Height	120 mm
Weight	5240 g
