English
SPEAKER CONNECTION
The Amp 5.1 offers you the possibility to combine up to 6 passive loudspeakers
with up to 8 wireless Smart speakers to an up to 7.1.4 channel home cinema
system. A maximum of 2 pairs of passive speakers, 3 pairs of Smart speakers and
one center and/or subwoofer each can be connected passively or wirelessly.
Connect passive speakers wired and/or Smart speakers wirelessly:
1
Enter the main menu by pressing the „M“ button. There, select the menu
item „Output Setup“ [OPS] using the up/down arrows
( / )
and press „OK“.
2
Select „Speaker Config“ [SPC] and confirm with the „OK“ button.
3
Select the speaker(s) to be configurated and press „OK“.
4
Now, you can use the „+/–“ buttons to set the type of the speaker(s) to be
configured and confirm with „OK“. The following are available:
For Front, Center, Surround, and Rear (Rear only with activated Surround):
• Smart (Wireless, with automatic size detection and adjustment)
• Large (Floorstanding speakers)
• Small (Bookshelf and small speakers)
• Off (Speaker not present in the setup. Not selectable for Front Left
and Front Right, they are mandatory.)
For Top Front and Top Rear (Top Rear only with activated Top Front):
• Smart (Wireless, with automatic size detection and adjustment)
• Ceiling loudspeaker (In- or ceiling-mounted passive speakers)
• Upfire (To the ceiling „beaming“ Dolby Atmos
®
enabled loudspeaker)
• Off (Speaker not present in the setup)
For Sub:
• Smart (Wireless)
• Analog (Wired connection of a powered/passive subwoofer)
• Off (Subwoofer not present in the setup)
