easy way ARIA +030220841 - rel. 1.0 - 26.10.2007
To access the information on the easy way system, the master-supervisor
must have the following settings:
CAREL master protocol;•
baud rate 19200.•
Below are the tables of supervisor variables for the components in the
system.
5.1 Access point variable list
par. description min max def UOM type index R/W notes
- Domain opening status 0 1 - - D 2 R
0= Network closed
1= Network open
-
Enable open/close domain
(see command set for variable I12)
0 1 - - D 3 R/W
0= standard operation
1= enable command I13
- Device CAREL address 1 15 - - I 2 R
- Number of sensors presenti 0 60 - - I 9 R
-
Commands (enabled with D3)
5266 Open network domain for associating the devices
5267 Close network domain for associating the devices
0 65535 - - I 13 R/W
Tab. 5.a
5.2 Terminal variable list
par. description min max def UOM type index R/W notes
- Ambient temperature
T&H T T&H T
-- °C A 1 R
-20.0 -7.0 80.0 55.0
- Ambient humidity (99.9 temperature-only model) 1.0 --- 100 --- -- %rH A 2 R
- Battery level 0.0 100.0 -- % A 3 R
- Minimum temperature variation to force transmission 0.1 5.0 1.0 °C A 4 R/W
- Minimum humidity variation to force transmission 1.0 10.0 5.0 %rH A 5 R/W
- Temperature set point 8.0 32.0 25.0 °C A 6 R/W
- Humidity set point 0.0 100.0 50.0 %rH A 7 R/W
- Indicative wireless signal level -100.0 -30.0 -- Dbm A 8 R
- Temperature delta in COMFORT -5.0 5.0 0.0 °C A 9 R/W
- Temperature from supervisor if D11=1 -40.0 80.0 0.0 °C A 10 W
- Humidity from supervisor if D11=1 1.0 100.0 0.0 %rH A 11 W
- Dead band for temperature calculation algorithm (AUTO mode) 0.0 25.0 0.0 °C A 12 W
-
Humidi cation algorithm di erential
0.0 algorithm disabled
0.0 25.0 5.0 %rH A 13 W
- Heating/cooling algorithm di erential 1.0 10.0 1.0 °C A 14 W
loc 5 Ambient temperature sensor calibration -9.5 9.5 0.0 °C A 15 R/W
loc 6 Ambient humidity sensor calibration -10.0 10.0 0.0 %rH A 16 R/W
loc 4 Temperature delta in Sleep mode (night) -5.0 5.0 0.0 °C A 17 R/W
-
Local temperature sensor alarm
0 no temperature sensor alarm
1 temperature sensor alarm
01 - D 4R
-
Local humidity sensor alarm
0 no humidity sensor alarm
1 humidity sensor alarm
01 - D 5R
-
ON/OFF
0 terminal o
1 terminal on
0 1 1 D 6 R/W
-
Sleep mode status
0 instrument not in sleep mode
1 instrument in sleep mode
0 1 0 D 7 R/W
-
Occupancy mode status
0 deactivated
1 active
0 1 0 D 8 R/W
-
Humidi cation request
0 request not active
1 request active
01 - D 9R
5. SUPERVISOR
