To Next Page

To Previous Page

SELECT

EXIT

SERVICE TABLE

Display Alarm History

(The table holds up to 25 alarms and

alerts with the most recent alarm

at the top of the screen.)

• CCM Thermistors

• CCM Pressure Transducers

• Pumps

• Discrete Outputs

• Slide Valve Control

• Head Pressure Output

• VFD Speed Control

• Pumpdown/Lockout

• Terminate Lockout

• Refrigerant Type

CONTINUED

ON NEXT PAGE

CONTROL ALGORITHM STATUS

CONTROL TEST

ALARM HISTORY

List the Control Tests

List the Control Algorithm Status Tables

• CAPACITY (Capacity Control)

• OVERRIDE (Override Status)

• LL_MAINT (Lead Lag Status)

• ISM_HIST (ISM Alarm History)

• LOADSHED

• WSMCHLRE (Water System Manager)

• OCCDEFCM (Time Schedule Status)

SELECT

EXIT

Select a Table

• NET_OPT

• BRODEF

• OCCEFCS

• HOLIDAYS

• CONSUME

• RUNTIME

(ANALOG VALUES)

(DISCRETE VALUES)

Select a Parameter

SELECT

EXIT

Modify a Parameter

ENTER

ENABLE

DISABLE

QUIT

DECREASE

INCREASE

ENTER

QUIT

SELECT

EXIT

Select a Table

EQUIPMENT CONFIGURATION List the Equipment Configuration Tables

• CAPACITY (Capacity Control Algorithm)

• OVERRIDE (Override Status)

• LL_MAINT (LEADLAG Status)

• WSMDEFM2 (Water System Manager Control Status)

Maintenance Table Data

SELECT

EXIT

Data Select Table

OCCPC01S (Local Status)

OCCPC02S (CCN, ICE BUILD Status)

OCCPC03S (CCN Status)

OCCDEFM (Time Schedule Status)

SELECT

EXIT

Select a Test

Fig. 21 — 23XL Service Menu Structure
