5 - PHYSICAL AND ELECTRICAL DATA FOR THE UNITS
5.1 - Physical data 30RB 170R-380R
30RB 170R 190R 210R 230R 270R 310R 340R 380R
Sound levels
Standard unit
Sound power
(1)
dB(A) 91,0 91,5 91,5 92,0 92,0 93,0 93,0 93,5
Sound pressure at 10 m
(2)
dB(A) 58,5 59,5 59,5 60,0 60,0 60,5 60,5 61,0
Unit + option 15LS
(3)
Sound power
(1)
dB(A) 85,5 85,5 85,5 86,5 86,0 87,5 87,0 88,0
Sound pressure at 10 m
(2)
dB(A) 53,0 53,5 53,5 54,5 54,5 55,5 55,5 55,5
Dimensions - standard unit
Standard unit
Length mm 2410 2410 2410 2410 2410 3604 3604 3604
Width mm 2253 2253 2253 2253 2253 2253 2253 2253
Height mm 2324 2324 2324 2324 2324 2324 2324 2324
Unit + option 307
(3)
Length mm 3604 3604 3604 3604 3604 4798 4798 4798
Operating weight
(4)
Standard unit kg 1349 1397 1397 1521 1556 1995 2049 2211
Unit + option 15LS
(3)
kg 1432 1480 1480 1630 1665 2122 2176 2356
Unit + option 15LS + option 116W
(3)
kg 1567 1615 1615 1765 1811 2271 2371 2551
Unit + option 15LS + option 116W + option 307
(3)
kg 2550 2598 2598 2748 2794 3258 3357 3537
Compressors Hermetic Scroll 48,3 r/s
Circuit A 1 1 1 2 2 2 2 3
Circuit B 2 2 2 2 2 3 3 3
Number of power stages 3 3 3 4 4 5 5 6
Unit PED category III III III III III III III III
Refrigerant
(4)
R32 / A2L /GWP= 675 as per AR4
Circuit A
kg 6,1 9,3 9,3 10,9 11,3 11,9 12,7 17,3
tCO
2
e 4,1 6,3 6,3 7,4 7,6 8,0 8,6 11,7
Circuit B
kg 10,9 10,9 10,9 10,9 11,3 16,7 17,5 17,3
tCO
2
e 7,4 7,4 7,4 7,4 7,6 11,3 11,8 11,7
Oil
Circuit A l 6,60 6,60 6,60 13,20 13,20 13,20 13,20 19,80
Circuit B l 13,20 13,20 13,20 13,20 13,20 19,80 19,80 19,80
Capacity control SmartVu
TM
Minimum capacity % 33 33 25 25 25 20 20 17
Condenser All-aluminium micro-channel coils (MCHE)
Fans Axial Flying Bird 6 with rotating shroud
Standard unit
Quantity 3 4 4 4 4 5 5 6
Maximum total air ow l/s 14460 19280 19280 19280 19280 24100 24100 28920
Maximum rotation speed r/s 16 16 16 16 16 16 16 16
Evaporator Direct expansion brazed-plate heat exchanger
Water volume l 15 15 15 19 27 27 35 44
Max. water-side operating pressure without hydraulic module kPa 1000 1000 1000 1000 1000 1000 1000 1000
Hydronic module (option)
Pump, Victaulic screen lter, relief valve,
water and air vent valve, pressure sensors
Pump
Centrifugal pump, monocell, 48,3 r/s, low- or high-pressure
(as required), single or dual (as required)
Expansion tank volume (Option) l 50 50 50 50 50 80 80 80
Bu󰀨er tank volume (option) l 550 550 550 550 550 550 550 550
Max. water-side operating pressure with hydraulic module kPa 400 400 400 400 400 400 400 400
Water connections with or without hydraulic module Victaulic
®
type
Connections inches 3 3 3 3 3 4 4 4
External diameter mm 88,9 88,9 88,9 88,9 88,9 114,3 114,3 114,3
Casing paint colour Colour code RAL 7035
(1) In dB ref=10
-12
W, (A) weighting. Declared dual-number noise emission value in accordance with ISO 4871 with an uncertainty of +/-3 dB(A). Measured in accordance
with ISO 9614-1 and certied by Eurovent.
(2) In dB ref 20 µPa, (A) weighting. Declared dual-number noise emission value in accordance with ISO 4871 with an uncertainty of +/-3 dB(A). For information, calculated
from the sound power Lw(A).
(3) Options: 15LS = Very low noise level, 116W = Variable-speed high pressure dual-pump hydraulic module, 307 = Water bu󰀨er tank module,
(4) Values are guidelines only. Refer to the unit name plate.
