11.4 - Fans
Each fan motor assembly is equipped with a high-performance impeller made from recyclable composite material.
The motors are three-phase, with lifetime lubricated bearings and class F insulation (IP55 level).
When option 12 is not selected, the pressure available at the fan outlet is zero.
According to regulation No. 327/2011 implementing directive 2009/125/EC with regard to ecodesign requirements for fans
driven by motors with an electric input power between 125 W and 500 kW.
Product 30RB/30RQ
Option 15LS
(for 30RB/30RQ)
30RBP/30RQP Option 12 Option 17
Overall e󰀩ciency % 38,7 35,3 40,1 40,0 47,3
Measurement category A A A A A
E󰀩ciency category Static Static Static Static Static
Target e󰀩ciency level ERP2015 N(2015) 40 N(2015) 40 N(2015) 40 N(2015) 40 N(2015) 40
E󰀩ciency level at the optimum
e󰀩ciency point
43,3 42,1 44,6 43,1 52,2
Speed regulator NO NO YES YES YES
Year of manufacture See label on the unit See label on the unit See label on the unit See label on the unit See label on the unit
Fan manufacturer Simonin Simonin Simonin Simonin Simonin
Motor manufacturer Leroy Somer Leroy Somer Leroy Somer Leroy Somer EBM
Fan PN 00PSG002630700A 00PSG002630700A 00PSG002630700A 00PSG002630700A 00PSG002630700A
Motor PN 00PPG000558400A 00PPG000558500A 00PPG000558700A 00PPG000558600A 00PSG002696800A
Nominal motor capacity kW 1,9 0,85 1,96 4,2 1,68
Flow rate m
3
/s 4,22 3,1 4,22 5,31 4,24
Pressure at optimum energy
e󰀩ciency
Pa 174 96,7 174 216 174,6
Nominal Speed rpm 949 710 948 1125 959
Specic ratio 1,002 1,002 1,002 1,002 1,002
Relevant information to facilitate the
disassembly, recycling or removal of
the product at the end of life
See the
Maintenance manual
See the
Maintenance manual
See the
Maintenance manual
See the
Maintenance manual
See the
Maintenance manual
Relevant information to minimise
impact on the environment
See the
Maintenance manual
See the
Maintenance manual
See the
Maintenance manual
See the
Maintenance manual
See the
Maintenance manual
Regulation 2019/1781 repealing regulation 640/2009 governs the requirements relating to ecodesign applicable to electric
motors and to speed regulators in accordance with directive 2009/125/EC. Our fan motor assemblies are exempt from this.
Product 30RB/30RQ
Option 15LS
(for 30RB/30RQ)
30RBP/30RQP Option 12 Option 17
Motor type Asynchronous Asynchronous Asynchronous Asynchronous Synchronous
Number of poles 6 8 6 6 -
Rated input frequency Hz 50 50 50 60 50
Nominal voltage V 400 400 400 400 400
Number of phases 3 3 3 3 3
Motor included in the scope of
application of regulation
2019/1781
NO NO NO NO NO
Justication for exemption Article 2.1 Article 2.1 Article 2.1 Article 2.1 Article 2.1
Ambient air temperature for
which the motor is specically
designed
°C 70 70 70 70 70
The above data for fans and motors, are mandatory as part of ecodesign regulations, and are provided for a standalone component
(not included in the cooling system).
11 - MAIN COMPONENTS OF THE UNIT AND OPERATING CHARACTERISTICS
49
