10-1-1. Installation Diagram of Indoor and Outdoor Units
Shield pipe
A
ir
f
ilt
e
r
Hook
Hook
(Attach to the front panel.)
65 mm or more
170 m
m or more
1 Installation plate
170 mm or more
2Wireless remote control
3Batteries
4 Remote control holder
8 Pan head
wood screw
The auxiliary piping can be
connected to the left, rear left,
rear right, right, bottom right
or bottom left.
Insulate the refrigerant pipes
separately with insulation, not
together.
6 mm thick heat resisting
polyethylene foam
Rear
left
Left
Bottom left
Right
Rear right
Bottom
right
Wall
Do not allow the drain hose to
get slack.
Make sure to run the drain
hose sloped downward.
Cut the piping
hole sloped
slightly.
For the rear left and left piping
Insert the cushion between
the indoor unit and wall, and
tilt the indoor unit for better
operation.
100 mm or more
600 mm or more
45 mm or more
100 mm or more
4
0
0
m
m
o
r
m
o
r
e
Saddle
Extension drain hose
(Not available, provided
by installer)
Vinyl tape
Apply after carrying
out a drainage test.
5
6
Before installing the
wireless remote control
• With the remote control cover
open, load the batteries supplied
correctly, obwerving their
polarity.
2
Wireless remote control
3
Batteries
A
C
L
Nano Silver
Ginseng filter
Nano-Photo
Copper Zinc filter
10. INSTALLATION PROCEDURE
FILE NO. SVM-07009
– 45 –
