FILE NO. SVM-07009
– 5 –
1. SPECIFICATIONS
1-1. Specifications
Unit model Indoor 42NQV025M, 42NQV025M-A
Outdoor 38NYV025M, 38NYV025M-A
Cooling capacity (kW) 2.5
Cooling capacity range (kW) 1.1 - 2.9
Heating capacity (kW) 3.2
Heating capacity range (kW) 0.9 - 4.0
Power supply 1Ph/50Hz/220-240V
Electric Indoor Operation mode Cooling Heating
characteristic Running current (A) 0.16 - 0.14 0.16 - 0.14
Power consumption (W) 30 30
Power factor (%) 87 87
Outdoor Operation mode Cooling Heating
Running current (A) 3.54 - 3.25 4.09 - 3.76
Power consumption (W) 740 855
Power factor (%) 95 95
Starting current (A) 4.25 - 3.90
COP (Cooling / Heating) 3.33 3.72 3.25/3.62
Operating Indoor High (Cooling / Heating) (dB-A) 39/41
noise Medium (Cooling / Heating) (dB-A) 34/36
Low (Cooling / Heating) (dB-A) 30/31
Outdoor (Cooling / Heating) (dB-A) 48/50
Indoor unit Unit model 42NQV025M, 42NQV025M-A
Dimension Height (mm) 250
Width (mm) 740
Depth (mm) 195
Net weight (kg) 8
Fan motor output (W) 20
Air flow rate (Cooling / Heating)
(m
3
/ min)
8.7/9.6
Outdoor unit Unit model 38NYV025M, 38NYV025M-A
Dimension Height (mm) 530
Width (mm) 660
Depth (mm) 240
Net weight (kg) 29
Compressor Motor output (W) 750
Type Single rotary type with DC-inverter variable speed control
Model DA89X1C-23FZ
Fan motor output (W) 20
Air flow rate (Cooling / Heating)
(m
3
/ min)
27/27
Piping Type Flare connection
connection Indoor unit Liquid side (mm)
∅6.35
Gas side (mm)
∅9.52
Outdoor unit Liquid side (mm)
∅6.35
Gas side (mm)
∅9.52
Maximum length (m) 10
Maximun charge-less length (m) 10
Maximum height difference (m) 8
Refrigerant Name of refrigerant R410A
Weight (kg) 0.63
Wiring Power supply 3 Wires: Includes earth (Outdoor)
connection Interconnection 4 Wires: Includes earth
Usable temperature range Indoor (Cooling / Heating)
(
o
C)
21 - 32/Up to 27
Outdoor (Cooling / Heating)
(
o
C)
15 - 43/-10 - 24
Accessory Indoor unit Installation plate 1
Wireless remote controller 1
batteries 2
Remote controller holder 1
Nano-Photo Copper Zinc filter 1
Nono-Silver Ginseng filter 1
Mounting screw
6 (∅4 x 25L)
Pan head wood screw
Installation manual 1
Owner's manual 1
Drain nipple 1
Water proof rubber cap -
2 (∅3.1 x 16L)
Plasma air purifier -
* The specification may be subject to change without notice for purpose of improvement.
Outdoor unit

Carrier 38NYV025M-A Specifications

General

Model	38NYV025M-A
SEER	Up to 20.5
Refrigerant	R-410A
Phase	1
Type	Heat Pump
Cooling Capacity	24, 000 BTU
Voltage	208-230V
Compressor Type	Inverter
Stages	Variable
Power Supply	208-230V, 60Hz
