13
Fig. 9 - Weight distribution (kg - approx.)
Point 38XTZ
007 008 011 014 016 020 024
12934504090105 110
23949506090105 110
330353680135139 141
4425264120 135 139 142
Point 40ABZ/ALZ*
007 008 011* 014* 016 020 024
121323754434653
248333855475153
320374263100104 110
446384364100104 109
* Models 40ALZ
38XTZ 007 and 008
38XTZ 014 to 024
40ABZ/ALZ
Fans
Control box
Air filters
