GENERAL
The 40VMF 4-way ceiling cassette effectively makes each area
served an independently controlled temperature zone. Through
thermostatic control of operations, conditions can be varied to
suit diverse requirements and activities.
The equipment is initially protected under the manufacturer’s
standard warranty; however, the warranty is provided under the
condition that the steps outlined in this manual for initial
inspection, proper installation, regular periodic maintenance,
and everyday operation of the unit be followed in detail. This
manual should be fully reviewed in advance before initial
installation, start-up, and any maintenance. Contact your local
sales representative or the factory with any questions BEFORE
proceeding.
Table 1 lists physical data for each unit size. See Fig. 1 for
model number nomenclature. Figure 2 shows unit dimensions.
Table 2 shows components that may or may not be used for a
particular installation.
Fig. 1 —Model Number Nomenclature
CAUTION
DO NOT re-use compressor oil or any oil that has been
exposed to the atmosphere. Dispose of oil per local codes
and regulations. DO NOT leave refrigerant system open to
air any longer than the actual time required to service the
equipment. Seal circuits being serviced and charge with
dry nitrogen to prevent oil contamination when timely
repairs cannot be completed. Failure to follow these
procedures may result in damage to equipment. For
information about replacement oil type and viscosity, see
the Installation, Start-Up, and Service Instructions for the
38VMAH and 38VMAR outdoor units.
40 VM F
009
--
3
Equipment Type
40 —
Indoor Unit
Product Type
VM — VRF
Blank
Voltage (V-Ph-Hz)
3 — 208/230-1-60
Model Type
F — 4-Way Cassette
Capacity (Btuh)
009
— 9,000
012
— 12,000
015
— 15,000
024
— 24,000
018
— 19,100
030
— 30,000
036
— 36,000
A40-1914
048
— 48,000
LEGEND
VRF — Variable Refrigerant Flow
A
Design Revision
To Next Page
