Table 18B — Thermistor Temperature (C) vs. Resistance/Voltage Drop
TEMPERATURE
(C)
PIC III
VOLTAGE
DROP (V)
RESISTANCE
(OHMS)
–33 4.722 105 616
–32 4.706 99 640
–31 4.688 93 928
–30 4.670 88 480
–29 4.650 83 297
–28 4.630 78 377
–27 4.608 73 722
–26 4.586 69 332
–25 4.562 65 205
–24 4.538 61 343
–23 4.512 57 745
–22 4.486 54 411
–21 4.458 51 341
–20 4.429 48 536
–19 4.399 45 819
–18 4.368 43 263
–17 4.336 40 858
–16 4.303 38 598
–15 4.269 36 476
–14 4.233 34 484
–13 4.196 32 613
–12 4.158 30 858
–11 4.119 29 211
–10 4.079 27 663
–9 4.037 26 208
–8 3.994 24 838
–7 3.951 23 545
–6 3.906 22 323
–5 3.861 21 163
–4 3.814 20 083
–3 3.765 19 062
–2 3.716 18 097
–1 3.667 17 185
0 3.617 16 325
1 3.565 15 513
2 3.512 14 747
3 3.459 14 023
4 3.406 13 341
5 3.353 12 696
6 3.298 12 087
7 3.242 11 510
8 3.185 10 963
9 3.129 10 444
10 3.074 9 949
11 3.016 9 486
12 2.959 9 046
13 2.901 8 628
14 2.844 8 232
15 2.788 7 855
16 2.730 7 499
17 2.672 7 160
18 2.615 6 839
19 2.559 6 535
20 2.503 6 246
21 2.447 5 972
22 2.391 5 711
23 2.335 5 463
24 2.280 5 226
25 2.227 5 000
26 2.173 4 787
27 2.120 4 583
28 2.067 4 389
29 2.015 4 204
30 1.965 4 028
31 1.914 3 861
32 1.865 3 701
33 1.816 3 549
34 1.768 3 404
35 1.721 3 266
36 1.675 3 134
37 1.629 3 008
38 1.585 2 888
39 1.542 2 773
40 1.499 2 663
41 1.457 2 559
42 1.417 2 459
43 1.377 2 363
TEMPERATURE
(C)
PIC III
VOLTAGE
DROP (V)
RESISTANCE
(OHMS)
44 1.338 2 272
45 1.300 2 184
46 1.263 2 101
47 1.227 2 021
48 1.192 1 944
49 1.158 1 871
50 1.124 1 801
51 1.091 1 734
52 1.060 1 670
53 1.029 1 609
54 0.999 1 550
55 0.969 1 493
56 0.941 1 439
57 0.913 1 387
58 0.887 1 337
59 0.861 1 290
60 0.835 1 244
61 0.811 1 200
62 0.787 1 158
63 0.764 1 117
64 0.741 1 079
65 0.719 1 041
66 0.698 1 006
67 0.677 971
68 0.657 938
69 0.638 906
70 0.619 876
71 0.601 846
72 0.583 818
73 0.566 791
74 0.549 765
75 0.533 740
76 0.518 715
77 0.503 692
78 0.488 670
79 0.474 648
80 0.460 628
81 0.447 608
82 0.434 588
83 0.422 570
84 0.410 552
85 0.398 535
86 0.387 518
87 0.376 502
88 0.365 487
89 0.355 472
90 0.344 458
91 0.335 444
92 0.325 431
93 0.316 418
94 0.308 405
95 0.299 393
96 0.291 382
97 0.283 371
98 0.275 360
99 0.267 349
100 0.260 339
101 0.253 330
102 0.246 320
103 0.239 311
104 0.233 302
105 0.227 294
106 0.221 286
107 0.215 278
108 0.210 270
109 0.205 262
110 0.198 255
111 0.193 248
112 0.188 242
113 0.183 235
114 0.178 229
115 0.174 223
116 0.170 217
117 0.165 211
118 0.161 205
119 0.157 200
120 0.153 195
