Water heat exchanger
Flooded multi-pipe
Water content
l
127
135
147
175
175
175
175
Max. water-side pressure w/o
hydronic module
kPa
1000
1000
1000
1000
1000
1000
1000
4.3 30XQ1150-1502 physical data
Model Code
30XQ
1150
1200
1230
1300
1340
1370
1400
1450
1502
Capacity Range
13%~100%
12%~100%
12%~100%
15%~100%
15%~100%
15%~100%
14%~100%
15%~100%
15%~100%
Refrigerant Charge
HFC-134a
Circuit A
kg
240
250
255
240
240
250
255
255
255
Circuit B
kg
-
-
-
-
-
-
-
-
-
Circuit C
kg
160
160
160
205
240
240
240
250
255
Circuit D
kg
-
-
-
-
-
-
-
-
-
Compressor
Semi-hermetic Screw Compressor
Motor cooling mode
Refrigerant suction cooling
Circuit A
1
1
1
1
1
1
1
1
1
Circuit B
-
-
-
-
-
-
-
-
-
Circuit C
1
1
1
1
1
1
1
1
1
Circuit D
-
-
-
-
-
-
-
-
-
Air heat exchanger
Cu-Al heat exchanger
Fans
Axial Flying Bird IV with rotating shroud
Quantity
20
20
20
24
24
24
24
24
24
Total air flow
l/s
90280
90280
90280
108336
108336
108336
108336
108336
108336
Fan speed
r/s
16
16
16
16
16
16
16
16
16
Water heat exchanger
Flooded multi-pipe
Water content
l
213
213
221
220
238
238
246
246
254
Max. water-side pressure w/o
hydronic module
kPa
1000
1000
1000
1000
1000
1000
1000
1000
1000
Notes: Unit sizes 30XQ1150 to 1502 are supplied in two field-assembled modules.
