Casio Exilim EX-S10 User Manual

49
Recording Movie Images and Audio
About audio data
• Audio files can be played back on a computer with Windows Media Player or
QuickTime.
– Audio Data: WAVE/IMA-ADPCM (WAV extension)
– Audio File Size: Approximately 165KB (Approximately 30 seconds of recording
at 5.5KB per second)
1. In the PLAY mode, use [4] and [6] to display
the Voice Recording file you want to play.
` is displayed in place of an image for a Voice
Recording file.
2. Press [SET] to start playback.
Voice Recording Playback Controls
To play back an audio recording
Fast forward/fast reverse [4] [6]
Play/pause [SET]
Jump to marker
While playback is paused, press [
4] or [6] to
jump to the next marker and then press [SET]
to resume playback.
Volume adjustment Press [2] and then press [8] [2]
Monitor screen on/off [8] (DISP)
Playback end [MENU]
C

Casio Exilim EX-S10 Specifications

General

Megapixel	10 MP
Camera type	Compact camera
Sensor type	CCD
Image sensor size	1/2.3 \
Maximum image resolution	3648 x 2736 pixels
Digital zoom	4 x
Optical zoom	3 x
Focal length range	6.3 - 18.9 mm
Digital SLR	No
Built-in flash	Yes
Power consumption (typical)	4.2 W
Focal length (35mm film equivalent)	36 - 108 mm
Auto focusing (AF) modes	continuous auto focus, multi point auto focus, spot auto focus
Light metering	Centre-weighted, Spot
ISO sensitivity	50, 100, 200, 400, 800, 1600
Light exposure modes	Auto
Internal memory	11.8 MB
Compatible memory cards	mmc, sd
Video formats supported	MOV
Maximum video resolution	848 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	959 pixels
I/O ports	A/V
USB version	2.0
Image editing	resizing, rotating, trimming
White balance	auto, daylight, Fluorescent, manual, Shade, Tungsten
Camera playback	movie, single image, slide show
Self-timer delay	10 s
Playback zoom (max)	8 x
Product color	Black
Number of batteries supported	1
Flash modes	auto, Flash off

Weight and Dimensions

Depth	14.9 mm
Width	94 mm
Height	54.5 mm
Weight	112.5 g
