81
Other Playback Functions (PLAY)
Procedure
[p] (PLAY) * Movie Screen of Movie to be Edited * [MENU] *
PLAY Tab * Movie Editing
The Movie Editing feature lets you use one of the following procedures to edit out a
specific part of a movie.
1. Use [8] and [2] to select the editing method you want to use and then
press [SET].
2. Use [4] and [6] to scroll through the movie
and search for the frame (point) from which
or to which you want to cut the movie (the cut
point).
You also can search for the cut location by
playing back the movie and pressing [SET] to
pause. During playback, you can press [4] or [6]
to perform fast reverse or fast forward.
3. When the frame where you want the cut point to be is displayed, press
[2].
4. Use [8] and [2] to select “Yes” and then press [SET].
The selected cut operation will take considerable time to complete. Don’t try to
perform any camera operation until the “Busy... Please wait...” message
disappears from the monitor screen. Note that a cut operation can take a long
time if the movie being edited is long.
Editing a Movie on the Camera (Movie Editing)
Cut (To-Point Cut)
Cuts everything from the beginning of the movie
up to the current location.
Cut (Point-To-Point Cut) Cuts everything between two points.
Cut (From-Point Cut)
Cuts everything from the current location to the
end of the movie.
Cut
(To-Point Cut)
While the frame you want the cut to be up to is
displayed, press [2].
Cut
(Point-To-Point Cut)
1
While the frame you want the first (From) cut to be is
displayed, press [2].
2
While the frame you want the second (To) cut to be
is displayed, press [2].
Cut
(From-Point Cut)
While the frame you want the cut to be from is
displayed, press [2].
}
~
¡
Cut range (red)
C

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio Exilim EX-S10 and is the answer not in the manual?

Casio Exilim EX-S10 Specifications

General IconGeneral
Megapixel10 MP
Camera typeCompact camera
Sensor typeCCD
Image sensor size1/2.3 \
Maximum image resolution3648 x 2736 pixels
Digital zoom4 x
Optical zoom3 x
Focal length range6.3 - 18.9 mm
Digital SLRNo
Built-in flashYes
Power consumption (typical)4.2 W
Focal length (35mm film equivalent)36 - 108 mm
Auto focusing (AF) modescontinuous auto focus, multi point auto focus, spot auto focus
Light meteringCentre-weighted, Spot
ISO sensitivity50, 100, 200, 400, 800, 1600
Light exposure modesAuto
Internal memory11.8 MB
Compatible memory cardsmmc, sd
Video formats supportedMOV
Maximum video resolution848 x 480 pixels
Display diagonal2.7 \
Display resolution (numeric)959 pixels
I/O portsA/V
USB version2.0
Image editingresizing, rotating, trimming
White balanceauto, daylight, Fluorescent, manual, Shade, Tungsten
Camera playbackmovie, single image, slide show
Self-timer delay10 s
Playback zoom (max)8 x
Product colorBlack
Number of batteries supported1
Flash modesauto, Flash off
Weight and Dimensions IconWeight and Dimensions
Depth14.9 mm
Width94 mm
Height54.5 mm
Weight112.5 g
