Casio Exilim EX-S10 User Manual

93
Printing
You can connect the camera directly to a printer that supports PictBridge and print
images without going through a computer.
. To set up the camera before connecting to a printer
1. Turn on the camera and press [MENU].
2. On the “Set Up” tab, select “USB” and then press [6].
3. Use [8] and [2] to select “PTP (PictBridge)”, and then press [SET].
. Connecting the Camera to a Printer
Use the USB cable that
comes bundled with the
camera to connect the
camera to your printer’s USB
port.
• The camera does not draw
power over the USB cable.
Make sure the camera’s
battery is sufficiently
charged before connecting.
• Make sure that you insert
the cable connector into
the USB/AV port until you
feel it click securely into
place. Failure to insert the
connector fully can result in
poor communication or malfunction.
• Note that even while the connector is fully inserted, you still will
be able to see the metal part of the connector as shown in the
illustration.
• When connecting the USB cable to a USB port, make sure you
align the connector correctly with the port.
. To print
1. Turn on the printer and load paper.
2. Turn on the camera.
This will display the print menu screen.
3. Use [8] and [2] to select “Paper Size”, and
then press [6].
Connecting Directly to a PictBridge Compatible Printer
USB
USB cable
USB port
USB/AV port
Making sure that the 2 mark on
the camera is aligned with the 8
mark of the USB cable connector,
connect the cable to the camera.
Large
connector
Small
connector

Casio Exilim EX-S10 Specifications

General

Megapixel	10 MP
Camera type	Compact camera
Sensor type	CCD
Image sensor size	1/2.3 \
Maximum image resolution	3648 x 2736 pixels
Digital zoom	4 x
Optical zoom	3 x
Focal length range	6.3 - 18.9 mm
Digital SLR	No
Built-in flash	Yes
Power consumption (typical)	4.2 W
Focal length (35mm film equivalent)	36 - 108 mm
Auto focusing (AF) modes	continuous auto focus, multi point auto focus, spot auto focus
Light metering	Centre-weighted, Spot
ISO sensitivity	50, 100, 200, 400, 800, 1600
Light exposure modes	Auto
Internal memory	11.8 MB
Compatible memory cards	mmc, sd
Video formats supported	MOV
Maximum video resolution	848 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	959 pixels
I/O ports	A/V
USB version	2.0
Image editing	resizing, rotating, trimming
White balance	auto, daylight, Fluorescent, manual, Shade, Tungsten
Camera playback	movie, single image, slide show
Self-timer delay	10 s
Playback zoom (max)	8 x
Product color	Black
Number of batteries supported	1
Flash modes	auto, Flash off

Weight and Dimensions

Depth	14.9 mm
Width	94 mm
Height	54.5 mm
Weight	112.5 g
