Casio Exilim EX-ZR700 User Manual

173
Appendix
. If the camera’s back lamp starts flashing red...
If the back lamp starts flashing red during charging, it means that further charging is
not possible for one of the reasons below. Perform the actions described below to
correct the problem and then try charging again.
Ambient temperature or the temperature of the battery is abnormally high
or low
Unplug the USB cable from the camera and wait for a while until the camera is within
the temperature range of 15°C to 35°C (59°F to 95°F), and then try charging again.
Safety timer activated
A battery that has not been used for a long time, certain types of computers, and
connection conditions can cause charging to take longer than normal. If charging
takes longer than about 5 hours, a safety timer will terminate it automatically, even if
the battery is not fully charged. If the battery has not been used for a very long time,
charging may terminate automatically after only about 60 minutes.
1) Using a battery that has not been used for a long time.
Disconnect and then reconnect the USB cable to resume charging.
2) Insufficient power supply when connected to computer
The camera can be charged only via a USB 2.0 standard USB port. Connect
directly to a USB port what supplies a current of 500mA.
For details about the power supply capacity of a computer’s USB port, contact the
manufacturer of the computer. Though disconnecting and then reconnecting the USB
cable will resume charging, you may need to do so repeatedly if the power supply
capacity of the computer is low.
Power Supply
Charging
If problems persist after you perform the above steps or if the battery fails to
charge after 5 hours, it could mean that the battery is faulty. Contact your nearest
CASIO authorized service center.

Casio Exilim EX-ZR700 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	18 x
Combined zoom	286.9 x
Focal length range	4.5 - 81 mm
Maximum aperture number	7
Minimum aperture number	3.5
Lens structure (elements/groups)	11/10
Maximum focal length (35mm film equiv)	450 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.04 - 0.5 m
Auto Mode focusing range (wide)	0.04 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Red-eye reduction
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.4 - 3.5 m
Flash recharging time	5 s
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution	640 x 1440 pixels
Display resolution (numeric)	921600 pixels
USB version	2.0
Product color	Red
Scene modes	-
White balance	Auto, Daylight, Manual, Shade, Tungsten
Self-timer delay	2, 10 s
Battery type	NP-130
Battery life (max)	6.25 h
Battery life (CIPA standard)	470 shots
Cables included	USB

Weight and Dimensions

Depth	30.7 mm
Width	107.4 mm
Height	60 mm
Weight	182 g
Weight (including battery)	222 g
