Casio Exilim EX-ZR700 User Manual

186
Appendix
Display Messages
ALERT
The camera’s protection function may have activated
because camera temperature is too high. Turn off the
camera and wait until it cools down before trying to use it
again.
Battery is low. Battery power is low.
Can not find the file.
The image you specified with the slideshow “Images”
setting cannot be found. Change the “Images” setting (page
119) and try again.
Card ERROR
There is something wrong with the memory card. Turn off
the camera, remove the memory card and then reload it
into the camera. If this message re-appears when you turn
the camera back on, format the memory card (page 162).
IMPORTANT!
• Formatting a memory card deletes all its files. Before
formatting, try transferring recoverable files to a
computer or some other storage device.
Check connections!
You are attempting to connect the camera to a printer while
the camera’s USB settings are not compatible with the USB
system of the printer (page 131).
Connecting to the
network
Camera power was turned off while image data was being
copied to a computer or other device using a FlashAir card
or an Eye-Fi card (pages 146, 148).
File could not be
saved because
battery is low.
Battery power is low, so an image file could not be saved.
Folder cannot be
created.
You are trying to record a file while there are already 9999
files stored in the 999th folder. If you want to record more,
delete files you no longer need (page 33).
LENS ERROR
This message appears and the camera turns off whenever
the lens performs some unexpected operation. If the same
message appears after you turn power back on, contact a
CASIO authorized service center or your original retailer.
LENS ERROR 2
The Anti Shake unit of the camera may be malfunctioning.
If the same message appears after you turn power back on,
contact your retailer or a CASIO authorized service center.
Load paper! The printer ran out of paper while printing.

Casio Exilim EX-ZR700 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	18 x
Combined zoom	286.9 x
Focal length range	4.5 - 81 mm
Maximum aperture number	7
Minimum aperture number	3.5
Lens structure (elements/groups)	11/10
Maximum focal length (35mm film equiv)	450 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.04 - 0.5 m
Auto Mode focusing range (wide)	0.04 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Red-eye reduction
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.4 - 3.5 m
Flash recharging time	5 s
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution	640 x 1440 pixels
Display resolution (numeric)	921600 pixels
USB version	2.0
Product color	Red
Scene modes	-
White balance	Auto, Daylight, Manual, Shade, Tungsten
Self-timer delay	2, 10 s
Battery type	NP-130
Battery life (max)	6.25 h
Battery life (CIPA standard)	470 shots
Cables included	USB

Weight and Dimensions

Depth	30.7 mm
Width	107.4 mm
Height	60 mm
Weight	182 g
Weight (including battery)	222 g
