QW-3410
– 11 –
6-2. REMOVING THE SENSOR
1) Remove the Bezel.
Bezel
The CAP/SENSOR may come off
the Bezel. Do not misplace it.
2) Undo two screws and the Plate/Protection.
Screws
Plate/Protection
3) Remove the Plate and O-ring.
Plate
O-ring
4) Remove the Sensor.
Sensor
