E-14
3. Load the battery pack into the Handheld Printer Terminal.
1 Turn the battery pack cover lock
switch on the side of the Handheld
Printer Terminal to the “FREE”
position.
2
Open the battery pack cover.
3 Install the battery pack (DT-9723LIC).
Push it all way to the end inside the
compartment until the eject button at
the front of the battery compartment
comes up (and sounds).
Make sure the battery pack is aligned
correctly when you install it.
4 Return the battery pack cover to its
original position as shown in the
illustration, and then turn the battery
pack cover lock switch to the
“LOCK” position.
4. Hold down the power key for about one
second to turn on the power. Start up
the application you want to run.
Before Getting Started
