Casio Privia PX-770 User Manual

EN-38
USB Flash Drive (PX-870)
2. While holding down the FUNCTION button,
press the keyboard key that corresponds to
the USB flash drive mode.
• This will cause the L/R lamps to flash.
3. While holding down the FUNCTION button,
press the format USB flash drive keyboard
key.
• This will cause the AUDIO REC lamp to light.
• To cancel the format operation, hold down the
FUNCTION button as you press the USB flash drive
mode key.
4. Press the a button.
• This starts formatting.
• After formatting is complete, the L/R lamps will go
out and the Digital Piano will exit the formatting
operation.
NOTE
• Formatting a large-capacity USB flash drive can take
several minutes.
Use the procedure below to save data you recorded on
the Digital Piano to a USB flash drive as a MIDI file
(SMF format 0).
1. Insert the USB flash drive into the Digital
Piano’s USB flash drive port.
2. While holding down the FUNCTION button,
press the keyboard key that corresponds to
the USB flash drive mode.
• This will cause the L/R lamps to flash.
Flashing
Lit
Flashing
Saving a Recorded Song to a
USB Flash Drive
Flashing Unlit
Formatting
started
Formatting
complete
Flashing

Casio Privia PX-770 Specifications

General

Product color	White
USB port	Yes
Headphone outputs	2
USB connector type	USB Type-B
Keys quantity	88 keys
Number of keyboard sensitivity levels	3
Sound effects	Brilliance, Chorus, Flanger/Digital Signal Processing (DSP), Reverberation
Tones quantity	19
Brilliance type	-3 to 0 to 3
Tweeter diameter	120 mm
Metronome tempo range	20 - 255 bpm
Amplifier output power	16 W
Metronome beats per bar	0, 9
Maximum polyphony (notes)	128
Music memory capacity (songs)	10
Reverberation effects quantity	4
Adjustable tone range (octaves)	-2 - 2
Demo songs quantity	60
Mobile operating systems supported	Android, iOS
Recorder/sequencer number of songs	1
Power consumption (min)	18 W

Weight and Dimensions

Depth	299 mm
Width	1391 mm
Height	798 mm
Weight	31500 g
