en 8
28
Specifications
Input voltage 220-240 VAC, 50/60 Hz
Max. pulling force 550 N
Standby Power (door closed) 0.8 W
Motor type DC gearmotor permanent
lubrication
Noise level 55dB
Drive Mechanism Belt
Length of Travel 2498 mm
Opening speed, up to 100 mm/s
Max. door weight 80 kg
Max. door dimensions,
height/width
2,125 m / 3,50 m
Lamp On when door starts, off 2-1/2
minutes after stop.
Door Linkage Adjustable door arm. Pull cord
trolley release
Safety, Personal Push button and automatic stop
in down direction. Push button and
automatic stop in up direction.
Electronic Automatic force adjustment
Electrical Transformer overload protector
and low voltage push button wiring.
Limit Device Mechanical RPM/Passpoint
detector
Limit Adjustment Electronic
Soft-Start / Soft-Stop Yes
Length (Overall) 3151 mm
Headroom Required min. 35 mm
Hanging Weight ~ 10 kg
Memory Registers 16
Operating Frequency: RX 433MHz (433.30MHz, 433.92MHz,
434.54MHz)
RX 868MHz (868.30MHz, 868.95MHz,
869.85MHz)
Transmitter Model TX4REV-F
Transmitter Frequency 868.30MHz, 868.95MHz, 869.85MHz
Sending power Transmitter < 10 mW
Transmitter Battery 3V CR2032
29
30
31
32
Door dimensions and -weight
Service parts / Warranty
Accessories (optional)
Declaration of conformity
One piece doors
max. width (mm) 3500
max. height (mm) 2125
max. weight (kg) 80
Sectional doors
max. width (mm) 3500
max. height (mm) 2125
max. weight (kg) 80
Your statutory rights are not affected by this manufacturer‘s warranty.
Please see www.chamberlain.eu for terms of warranty.
Always use Chamberlain accessories.
External products can cause malfunctions.
1. TX4RUNI 4-channel universal remote control
2. 128REV Wireless Wall Control 2-Channel
3. 747REV Keypad
4. 1REV Quick release
5. 1702REV Quick release
6. 75REV Wired push button
7. 771EV Photocells
8. 41REV Key switch (surface mount)
The manual consists of these operating instructions and the declaration
of conformity.
The radio equipment type (TX4REV-F) is in compliance with
Directive 2014/53/EU and for UK with Radio Equipment Regulation SI
2017 No. 1209. The full text of the EU declaration of conformity is availa-
ble at the following internet address: https://doc.chamberlain.de/
33
Intended area of use
The drive must not be used in potentially explosive areas, in extremely
salty air or in an aggressive atmosphere. The door must not be part
of a fire protection system, an escape route or an emergency exit that
automatically closes the gate in the event of a fire. Local building regu-
lations must be observed. In the event of damage caused by other and
non-intended use, the manufacturer‘s warranty expires due to use with
defective parts, unauthorized changes to the drive, modifications to the
drive and its components.
34 Storage & Disassembly
The drive must be stored as follows:
- in closed and dry and closed rooms, protected from moisture
- Storage temperature from –25 °C to +65 °C
- Secured against falling over and allow unhindered passage
When decommissioning or dismantling, the drive and its accessories
must be disconnected from any power supply.
1. Pull the main plug out of the socket and then check that there is no
voltage.
2. Disassembly is in reverse order to assembly.
