Taillamps, Stoplamps and
Back-up Lamps
A. Rear Sidemarker
Lamp
B. Taillamp/Turn Signal
and Stoplamp
C. Taillamp
To replace one of these bulbs, do the following:
1. Open the trunk. See Trunk on page 101
for more information.
2. Remove the convenience net, if your vehicle
has one, and then remove it by unhooking
the upper wing nut.
3. Pull the carpet away from the rear of the
vehicle.
4. Remove the two remaining wing nuts.
5. Pull the assembly from the vehicle.
6. Remove the bulb socket. To do so, press the
tab, turn it counterclockwise and pull it out.
7. Pull the old bulb straight out.
8. Push the new bulb into the bulb socket.
9. Reverse Steps 1 through 5 to reinstall the
taillamp assembly.
Back-Up Lamps
The back-up lamps are located in the rear bumper.
1. Remove the two screws from the back-up
lamp assembly.
2. Pull the assembly from the rear bumper.
345
