WARNING: Remove power from the controller before changing
the output module. Failure to do so could cause damage to
controller and/or personal injury or death from electrical shock.
When handling output modules, be careful to guard the module against
static discharge. Follow the steps below to remove an existing output
module and replace it with a new module.
Removal
1. Remove power from the controller.
2. Remove all terminal connections.
Section 6—Replacing Output Modules
The Chromalox 2110 Temperature Controller was shipped with the
output modules installed as ordered. The 10A Solid State Relay and 20A
Mechanical Relay output cards control small cartridge heater or strip
heater loads directly, eliminating the need for a remote contactor or solid
state relay. If a larger load is required, the 2110 can be configured with a
1A Pilot Duty Relay or Solid State Relay Drive.
The 2110 may be optionally configured with a 5A/120V Alarm Relay.
Alternate modules, configured with or without alarm, can be installed as
needs change.
Control and alarm outputs can be changed in the field.
Module Option
Descriptions
17
Section 6–Replacing Output Modules
Factory
Load/Sourcing Default Part No Part No.
Description Specification Cycle Time w/o Alarm w/ Alarm
Output Module options are as follows
R1 Relay
R3 Relay
V0 SSR Drive
S1 TRIAC
S1 Solid State
Power
Controller
S2 Solid State
Power
Controller
30 sec.
30 sec.
1 sec.
1 sec.
1 sec.
1 sec.
Form A contact, SPST,
N.O. 1.0 Amp at 120/240
VAC resistive load
Form A contact, SPST,
N.O. 20 Amp at 240 VAC,
28 VDC resistive load
24 VDC nominal at 40
mA
1 amp continuous, 10
Amp in-rush 120/240 VAC
120/240 VAC, 5 Amp @
40°C ambient
120/240 VAC, 10 Amp @
40°C ambient with built-
in cooling fan mounted
on rear of housing
0149-271470149-27133
0149-271460149-27132
0149-271490149-27135
0149-271480149-27134
0149-271500149-27136
0149-27150
0149-00022
(Fan Kit)
0149-27136
0149-00022
(Fan Kit)
Module Installation
!
continued
