Cisco 3600 Series User Manual

1-Port Fast Ethernet and 1-Port or 2-Port Channelized T1/ISDN PRI Network Modules
Cisco Network Modules Hardware Installation Guide
5-4
Figure 5-3 Connecting a Fast Ethernet RJ-45 Port to a Hub
Connecting the PRI Ports
This section describes how to connect channelized T1 and channelized E1 ISDN PRI ports
to the network. These ports are color-coded tan.
Use a DB-15-to-DB-15 T1 serial cable to connect a CT1/PRI port to a T1 channel service
unit (CSU). (See Figure 5-4.)
LOOP
BACK
EN
FE–PRI
1FE-1CT1
LOCAL
ALARM
REMOTE
ALARM
CARRIER
DETECT
CTRLR 0
10/100BaseT
COLL
LINK
100Mbps
FDX
H9984
Fast Ethernet
RJ-45
Fast Ethernet hub
Category 5
or UTP cable
